100~125kW Mars( Liquid cooling) Series High-Protection PCS Module for C&I BESS

Download

PARAMETERS

		Mars-100KT-LP	Mars-110KT-LP	Mars-125KT-LP
DC side	Max. DC voltage	1000V
	Min. DC voltage	580V
	DC voltage working range	580-1000V
	Maximum current on DC side	113A	190A	216A
AC side (on-grid)	Rated charge and discharge power	100kW	110kW	125kW
	Maximum charge/discharge power	120kW	132kW	150kW
	Rated charge/discharge current	145A	160A	182A
	Rated grid voltage	400V
	Allowed grid voltage range	300-460V
	Rated grid frequency	50Hz/60Hz
	Total harmonic distortion of current	≤3% (at rated power)
	Power factor	>0.99
	Power factor range	1月1日
	Overload capability	1.2Pn, last for one minute
AC side (off-grid)	Rated output voltage	400V
	Voltage deviation	±2%
	Total harmonic distortion of voltage	≤3% (linear load)
Efficiency	Maximum efficiency	99.00%
Protection	DC RCP	Yes
	AC SCP	Yes
	AC output OCP	Yes
	Surge Protection	Type II
	Insulation resistance detection	Yes
	Temperature protection	Yes
	DC switch	Yes
General	Dimensions (WHD) (mm)	505×254×875
	Weight	<15kg
	Topology	no transformer
	Working temperature	-40~+60℃
	IP level	IP65
	Cooling method	Liquid cooling
	Working altitude	<4000m (Derating above 3000m)
	Standby power consumption	<12W
Characteristics	DC connector	Front Exit Quick-Connect Terminal
	AC connector	Front Exit Quick-Connect Terminal
	Display	LED
	Communication mode	Ethernet, RS485, CAN
