Electree Sequoia 320-400kW Supergiant Charging Station
Electree Sequoia 320-400kW Super Charging Station
Key features
- Designed for the European market, this product has more powerful data calculation and processing capacity, smarter dispatching strategy, better heat dissipation performance and lower noise, and fully meets the requirements of high-power DC charging of vehicles with European and Japanese standard DC interface.
- The product has multiple protection design and active protective function, which can monitor all communication data in the charging process and give early warning to all kinds of abnormal charging to ensure the safety of users and vehicles.
PARAMETERS
| Rated power | 320kW | 400kW |
| Input Voltage | 400VAC±10%,3P+N+PE | |
| Output Voltage | 200-1000Vdc | |
| Output Current | CCS2 300A max. CHAdeMO 125A max. | |
| Operating temperature | -30 ~ +50°C | |
| Application Site | Indoor/Outdoor | |
| EVSE | PLC (DIN 70121: 2014-12 / ISO15118) | |
| Back-end protocol | Ethernet, 4G, OCPP 1.6J, OCPP 2.0（upgradeable） | |
Download
Electree Sequoia320-400kW data sheet
Details
PARAMETERS
| Rated power | 320kW | 400kW |
| Input Voltage | 400VAC±10%,3P+N+PE | |
| Output Voltage | 200-1000Vdc | |
| Output Current | CCS2 300A max. CHAdeMO 125A max. | |
| Operating temperature | -30 ~ +50°C | |
| Application Site | Indoor/Outdoor | |
| EVSE | PLC (DIN 70121: 2014-12 / ISO15118) | |
| Back-end protocol | Ethernet, 4G, OCPP 1.6J, OCPP 2.0（upgradeable） | |
