LCR100040A-40kW@1000V Liquid Cooling Charging Module
Key features:
- Full liquid cooling technology
- Hydroelectric separation design
- Wide constant power range of 300-1000V
- Full-load efficiency exceeds 95.5%
INTRODUCTION
LCR100040A is a high-frequency isolated liquid-cooled AC/DC charging module with core advantages such as ultra-wide voltage range, ultra-high full load liquid cooling operating temperature, super high efficiency. Suitable for harsh environments such as coastal areas and mining areas, with strong environmental adaptability.
ADVANTAGES
- Wide DC output voltage range of 50-1000Vdc to meet the charging voltage requirements of various electric models and battery packs.
- IP50 protection rating. Full liquid cooling technology significantly improves heat dissipation efficiency.
- The electromagnetic compatibility meets Class B standards, boasting low electromagnetic radiation and robust anti-interference capabilities.
- Featuring liquid cooling for silent noise operation, it is ideal for both residential and office areas.
PARAMETERS
| Input Voltage | 260～530 VAC, 3-Phase+PE, 45～65Hz |
| Input Current | <80A |
| Output Voltage Range | 100Vdc～1000Vdc |
| Output Current Range | 0A～133.3A |
| Dimensions | 340mm（H）×100mm（W）×470mm（D） |
| Weight | ≤ 28 kg |
Download
LCR100040A Power Module Data Sheet
Details
INTRODUCTION
LCR100040A is a high-frequency isolated liquid-cooled AC/DC charging module with core advantages such as ultra-wide voltage range, ultra-high full load liquid cooling operating temperature, super high efficiency. Suitable for harsh environments such as coastal areas and mining areas, with strong environmental adaptability.
ADVANTAGES
- Wide DC output voltage range of 50-1000Vdc to meet the charging voltage requirements of various electric models and battery packs.
- IP50 protection rating. Full liquid cooling technology significantly improves heat dissipation efficiency.
- The electromagnetic compatibility meets Class B standards, boasting low electromagnetic radiation and robust anti-interference capabilities.
- Featuring liquid cooling for silent noise operation, it is ideal for both residential and office areas.
PARAMETERS
| Input Voltage | 260～530 VAC, 3-Phase+PE, 45～65Hz |
| Input Current | <80A |
| Output Voltage Range | 100Vdc～1000Vdc |
| Output Current Range | 0A～133.3A |
| Dimensions | 340mm（H）×100mm（W）×470mm（D） |
| Weight | ≤ 28 kg |
